Hanging Server Rack
![](https://nerdlabprojects.com/rails/active_storage/blobs/redirect/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaHBhdz09IiwiZXhwIjpudWxsLCJwdXIiOiJibG9iX2lkIn19--a5f8d62190b3d3e48b6199749996eef00f19ada3/20200814_141900.jpg)
* Updated at: April 18, 2022
I needed a network rack for all my networking gear.
I have a Dream Machine Pro from Ubiquiti because I got tired of dealing with routers that would always have issues or need rebooted to be fixed. This beast of a machine solved all my networking issues and gave me great insight into my network. Only problem was I didnt quite have a great place to put it yet. I ended up gettings a couple server rack mounting rail kits and made my enclosure out of plywood.
Dimensions of the 3/4" plywood pieces are:
- 2x Sides 27" x 12"
- Top and Bottom 27" x 19"
- 2x Steel Rack Rail Set
- 1x 3D printed knob/latch
- 1x Cut out access door to a size of your choosing on the bottom
- 2 hinges for access door
Basic box cut and put together
Access Door
Scrap 2x4 to add extra support for the ceiling:
I used a guide to get a exact cutout I needed for the 2x4, this was not 100% necessary and a tape measure would do just fine.
Finished product with a mess of wires. I am half way in completing my cat 6a ethernet upgrade project for my house in this picture.
